Technical Data:
|
Type |
JBT80 |
JBT90 |
JBT101 |
JBT102 |
|
Min edge diameter |
40 mm |
40 mm |
40 mm |
40 mm |
|
Feeding speed |
5 m/min |
0.5-3.5 m/min |
0.5-8 m/min |
2-6 m/min |
|
Banding thickness |
0.3-3.0 mm |
0.3-3.0 mm |
0.3-3.0 mm |
0.6-3.0 mm |
|
Banding width |
10-45 mm |
10-45 mm |
10-45 mm |
10-60 mm |
|
Operating temperature |
120-170℃ |
120-170℃ |
120-180℃ |
120-180℃ |
|
Motor power |
15 w |
15 w |
20 w |
25 w |
|
Total power |
765 w |
765 w |
620 w |
725 w |
|
Glue pot volume |
270 ml |
270 ml |
300 g |
570 g |
|
Weight |
9.5 kgs |
9.5 kgs |
10kgs |
11kgs |
|
Machine size |
380*330*380 mm |
380*330*380 mm |
380*330*380 mm |
390*350*310 mm |
|
Independent packing size |
380*300*420 mm |
380*300*420 mm |
380*300*420 mm |
370*350*420 mm |
|
Whole package size |
465*430*515 mm |
465*430*515 mm |
465*430*515 mm |
465*430*515 mm |
|
0-45°Tilting |
no |
no |
Yes |
Yes |
|
Double Surface Gluing |
no |
no |
no |
Yes |
