Features： Technical Characteristics: 1. Famous Brand PLC. 2. Double servo motors for pulling film down system. 3. Automatically film recitifying function. 4. Adopt clip or supporting without broken bags; reduce waste. 5. Many kinds of languag
Technical Parameters:
|
Type |
SYX-920 |
|
Bag length |
100-570mm(L) |
|
Bag width |
180-450mm(W) |
|
Max roll film width |
920mm |
|
Packing speed |
5-40 bag/min |
|
Air consumption |
0.5m3/min 1.0Mpa |
|
Power voltage |
6KW 220V 50/60HZ |
|
Dimension |
(L)1750×(W) 1510×(H) 2100 mm |
|
Net weight |
1000KG
|
Technical Characteristics:
1. Famous Brand PLC.
2. Double servo motors for pulling film down system.
3. Automatically film recitifying function.
4. Adopt clip or supporting without broken bags ; reduce waste.
5. Many kinds of languages can be choosed.
