Features：Application: Suitable for packing regular objects such as biscuit, bread, instant, noodle, moon cakes, industrial parts, paper box or trays.
Application:
Suitable for packing regular objects such as biscuit, bread, instant, noodle, moon cakes, industrial parts, paper box or trays.
Technical parameters:
|
Type |
SYX-250B |
SYX-250D |
SYX-350B |
SYX-350D |
|
|
Film Width |
MAX.250mm |
MAX.350mm |
|||
|
Bag length |
65-90或120—280mm |
90—220mm |
56-190或120-280mm |
90-120或150-330mm |
|
|
Bag width |
30—110mm |
50—160mm |
|||
|
Product height |
MAX.40mm |
MAX.55mm |
MAX.40mm |
MAX.60mm |
|
|
Film roll diameter |
MAX.320mm |
MAX.320mm |
|||
|
Packing speed |
40—230 bags/min |
40—230 bags/min |
|||
|
Power |
220V50/60HZ2.6KW |
220V50/60HZ2.6KW |
|||
|
Machine size |
(L)3770×(W)670×(H)1450mm |
(L)4020×(W)800×(H)1450mm |
|||
|
Machine weight |
800Kg |
900Kg |
|||
Main performance and structure features:
1.Double transducer control, flexible bag length cutting, operator needn’t to adjust the unloadingworking, saving time and saving films.
2.Human-machine operation, convenient and quick parameter setting.
3.Self diagnosis failure function, clear failure display.
4.High sensitivity optical electric color mark tracking，digital input cut position which makes the sealing and cutting more accurate.
5.Separate PID control to temperature, suitable for various packing materials.
6.Stopping the machine in selected position, no sticking to the knife and no waste packing film.
7.Simple driving system, reliable working, convenient maintenance.
8.All the controls are achieved by software, convenient for function adjusting and upgrading.
